FEATURES

•XL04S-3 column has similar feature as XLO4-3

•With bracket support and downward profile,XLO4S-3column is strong enough where no crossbar is needed

SPECIFATIONS

Load Capacity push:    800
Static Load push:    38
Input:    24
Stroke Length：   650
Retracted length:   560
Color：   Black or Grey
Overload Protection：   integrated in appropriate Control-Box
Limit Switch：   No Limit Switch
Duty Cycle：   10% max 2min.continuous use
Inner Tube：        Steel
Operating Temperature：   +5℃~+40℃
Standard：   UL/CE
Recommend control box:    XK03
