FEATURES

•Column is designed for a wide ranfe of workstation applications,like computer workstations,work benches,assembly desks or kitchens

•With the Hall sensors built-in,XL02-2 can be operated either as single column or several columns in synchronized movement by choosing a control box with micro-processor

•Motor for hidden,products more beautiful,more small installation location

SPECIFATIONS
Stroke Length：   100-400（可选>400）
Color：   Black or Grey
Mounting:     By screws on the top and botton plate(option)
Overload Protection：   integrated in appropriate Control-Box
Limit Switch：   Built-in
Duty Cycle：   10% max 2min.continuous use
Inner Tube：   Aluminum tuble
IP Grade：  IP43
Operating Temperature：   +5℃~+40℃
Standard：   UL60601/CE
Operating Features:   Hall sensors option
