FEATURES

•Quiet and powerful design

•Up to 8000N load capacity

•Ldea for patient lift application

SPECIFATIONS

Load Capacity push：   8000
Static Load push ：   8000
Speed at No Load：   6
Speed at Full Load：   3

Input：   24
Stroke Length：   100-400（可选>400）mm
Mounting position：   Option H or O
Color：   Black or Grey
Limit Switch：   Built-in
Duty Cycle：   10% max 2min.continuous use
Overload Protection：   integrated in appropriate Control-Box
Inner Tube：   Aluminum tuble
Clevis：   Zinc-alloy
IP Grade：  IP54
Standard：   CE
Operating Temperature：   +5℃~+40℃
