FEATURES

•The track actuator with nut moving outside on profile
•The mounting dimension is fixed according to the stroke
•Ideal for recling chairs and TV Lift applications

SPECIFATIONS

Input：   24
Stroke Length：   100-400（可选>400）mm
Mounting position：   Option H
Color：   Black or Grey

Limit Switch：   Built-in
Duty Cycle：   10% max 2min.continuous use

Overload Protection：   integrated in appropriate Control-Box

Inner Tube：   Aluminum tuble
End clevis：   Plastic
IP Grade：  IP20
Standard：   CE
Operating Temperature：   +5℃~+40℃

Optional Features：Hall sensor option
                                  Relay free version
