FEATURES

•Quiet and powerful design

•Idea for homeware and medical market

SPECIFATIONS

Input：   24
Stroke Length：   100-400（可选>400）mm
Mounting position：   Option H or O
Color：   Black or Grey

Limit Switch：   Built-in
Duty Cycle：   10% max 2min.continuous use

Overload Protection：   integrated in appropriate Control-Box

Inner Tube：   Stainless steel tube
Top clevis：   Steel
End clevis：   Steel
IP Grade：  IP54
Standard：   CE/EN60601/UL60601
Operating Temperature：   +5℃~+40℃

Optional Features：  Read switch option
                                  Only push option
                                  Safety nut option
