FEATURES

•Basic and economic design
•Up to 6000N load capacity
•Direct mounting on Control Box possibility

SPECIFATIONS
Input：   24
Stroke Length：   100-400（可选>400）mm
Mounting position：   H,O and 45°
Color：   Black or Grey
Limit Switch：   Built-in
Duty Cycle：   10% max 2min.continuous use
Overload Protection：   integrated in appropriate Control-Box
Inner Tube：   Aluminum tuble
Top clevis：   Aluminum-Allov (Steel or Plastic is option accordina to the application)
End clevis：  Aluminum-Allov (Steel or Plastic is option accordina to the application)
IP Grade：  IP54
Standard：   CE/UL
Operating Temperature：   +5℃~+40℃
Optional Features：  Hall sensor option
                                  Read switch option
                                  Only push option
                                  Relay free version
